Salicru 698RQ000003 SLC TWIN RT2 5kVA/5kW 230V Online UPS

ETA confirmed after ordering or call: 0800 254 5655

ETA confirmed after ordering or call: 0800 254 5655

SKU:
698RQ000003
MPN:
698RQ000003
£2,347.60 £1,956.33
Salicru's SLC TWIN RT2 series UPSs can protect a wide range of environments, including virtualized or non-virtualized server systems, voice and data networks, ERP systems, CRM solutions, document management, and more.
Standard Delivery  (1 - 7 Days)

Salicru's SLC TWIN RT2 series UPSs can protect a wide range of environments, including virtualized or non-virtualized server systems, voice and data networks, ERP systems, CRM solutions, document management, and more. All of these depend on the reliability of the electrical supply that powers them. This uninterruptible power supply has electrical protection features that are unmatched for critical servers.

The dual tower/rack format can be used in any location and, with the built-in PDU strip, makes it easy to connect the loads that need to be protected. As a bonus, their output power factor (VA=W) is the same as their input power factor (VA=W), which increases the power density and reduces the space needed for the UPS to be installed.

The LCD screen is swivel-mounted to make it easier to move around. In terms of serial communications, they have USB, RS-232, and relay interfaces, as well as a smart slot that can be used to add an SNMP card, MODBUS, or potential-free contacts. There are also software packages that can be used to monitor and manage the devices that are being protected.

For applications that need a lot of battery power, extra battery modules and solutions with extra chargers can be used. For applications that need extra protection or more power, there is the option to connect up to three devices in parallel.

Features & Benefits:

  • Output power capacity: 5000 Watts / 5kVA
  • Online double-conversion technology
  • Unity output power factor PF=1
  • Convertible tower/rack format
  • Parallelable up to 3 units
  • Swivel-mount control panel
  • RS232 and USB-HID communication interfaces
  • Smart slot for SNMP and relays
  • Available backup extensions
  • Eco-mode operation
  • SLC Greenergy Solutions
  • Management software
  • Pure sine wave output
  • Backup battery for mains interruptions
  • Two-year warranty
  • Output Connections - Terminals + PDU
  • PDU Output Connections - 4 x IEC C13, 2 x IEC C19
  • Input Connections - Terminals

Please Note: Rack Rail Kit sold separately

Technical Specifications
TechnologyOn-line double-conversion
FormatConvertible tower/rack
Input
Voltage220 / 230 / 240 V
Voltage range110 ÷ 300 V up to 50% load
Rated frequency50 / 60 Hz (auto-detection)
Frequency range±4 Hz
Total harmonic distortion (THDi)≤4%
Output
Power factor1 (2)
Voltage208 / 220 / 230 / 240 V
Static accuracy±1%
Power (VA/W)5000 / 5000
Total harmonic distortion (THDv) Linear load<1%
Total harmonic distortion (THDv) Non~linear load<4%
Synchronised frequency±4 Hz
Frequency accuracy (battery mode)±0.1 Hz
Eco-mode performance≥99%
Total performance in Online mode≥93 ÷ 94%
Admissible overloads< 110% for 10 min / < 130% for 1 min / > 130 % for 1 s
Socket typeTerminals + PDU
ParallelYes, up to 3 units(3)
Static Bypass
Voltage (V)208 / 220 / 230 / 240 V (1)
Frequency range50/60 Hz ±4 Hz
Battery
ProtectionAgainst power surges, undervoltages and alternating current components
Battery typePb-Ca sealed, AGM, maintenance-free
Charge typeI/U (constant current/constant voltage)
Recharge time7 ÷ 9 hours to 90%
Charger
Temperature voltage compensationYes
Communication
PortsUSB / RS-232 / relay
Intelligent slotSmart slot for SNMP / potential-free contacts / MODBUS
Monitoring softwareYes, for Windows, Linux and Mac
Other Functions
Cold start (start-up from batteries)Yes
Emergency stop (EPO)Yes
Operating Modes
Frequency converter (CVCF)Yes(4)
General
Operating temperature0° C ÷ +40° C
Relative humidityUp to 95%, non-condensing
Maxium operating altitude2,400 masl (power degradation up to 5,000 m)
Acoustic noise at 1 metre< 60 dB
Standards
SafetyEN-IEC 62040-1
Electromagnetic compatibility (EMC)EN 62040-2(C3)
OperationEN 62040-3
Quality and environmental managementISO 9001 & ISO 14001
Dimensions
Depth (mm)705
Width (mm)438
Height (mm)176
Weight
Weight (kg)63

(1) 90% power reduction for 208 V devices

(2) Except for devices with extended backup

(3) 90% power reduction

(4) 60% power reduction
