FIAMM 12FGHL70 Long-Life High-Rate Performance (10-Year) VRLA Battery (12V 17Ah)

The FIAMM 12FGHL70 is a 12 V, 17 Ah long‑life high‑rate VRLA AGM battery, built for demanding applications where a 10‑year float service life is essential. Engineered under Eurobat High Performance standards, it’s ideal for UK B2B critical power systems—UPS, emergency lighting, telecom infrastructure, security systems and data centres. It offers sealed, maintenance‑free operation, 99 % gas recombination, and low self‑discharge for readiness even after extended storage. Housed in a flame‑retardant ABS UL94 V‑0 case with Faston 6.3 mm terminals, it delivers reliable connectivity and durability. UPSBuyer holds this battery in stock, with UK-wide delivery, full warranty and specialist technical support.

Features & Benefits

• 10‑year float life: Designed for extended service life and reduced replacements.
• High-rate capability: Delivers strong performance for peak loads—17 Ah capacity suits UPS and alarms.
• Sealed VRLA AGM: Non‑spillable, maintenance-free and can be installed in any orientation.
• 99 % gas recombination: Preserves electrolyte and prolongs lifespan.
• Low self‑discharge: Less than 2 % per month ensures retained capacity.
• Faston 6.3 mm terminals: Secure, high-current connections for demanding applications.
• Flame-retardant housing: ABS UL94 V‑0 case for enhanced safety and compliance.
• UPSBuyer UK support: Nationwide delivery, warranty coverage, and expert assistance.

Technical Specifications

• Model: 12FGHL70
• Voltage: 12 V
• Capacity: 17 Ah (20 h rate to 1.75 Vpc at 25 °C)
• Design Life: 10 years float (Eurobat High-Performance)
• Internal Resistance: approx. 37 mΩ (based on similar FGH/FGHL data)
• Dimensions (L×W×H): 151x98x95mm
• Terminal Height: 100mm
• Weight: 4.0kg
• Terminal Type: Faston 6.3
• Case Material: Flame-retardant ABS UL94 V‑0
• Operating Temp Range: –20 °C to +50 °C
• Self‑discharge: <2 % per month at 20–25 °C
• Certifications: IEC 60896‑21/22, UL recognised, Eurobat 10–12 year high‑performance
