The Step-Down Transformer converts high voltage (208 or 200 VAC) output to low voltage (120 or 100 VAC) output, allowing low voltage AC equipment to be powered.
The Step-Down Transformer converts high voltage (208 or 200 VAC) output to low voltage (120 or 100 VAC) output, allowing low voltage AC equipment to be powered.
Includes - Documentation CD, Hardwire panel, Installation guide, Mounting hardware, Rack mounting brackets, User manual.
Features & Benefits:
Key Features |
|
|---|---|
| Rack Height | 4U |
| Output Connections | (1) Hard wire 3-wire (H N + E) (1) Hard wire 4-wire (2P + N + E) |
| Nominal Output Voltage | 100V, 120V, 200V, 208V, 230V |
| Nominal Input Voltage | 100V, 120V, 200V, 208V, 230V, 400V 3PH |
| Input Connections | Hard wire 3-wire (1P + N + E), Hard wire 3-wire (2P + E), Hard wire 4-wire (2P + N + E) |
| Rack-Mountable | Only takes up 1U of critical rack space. Places power where it is most required - in the rack near the equipment. |
| Transformer for Step-down or Step-up or Isolation | To reduce inrush current and saturation, a step down transformer is positioned upstream of the UPS, reducing the requirement for an oversize transformer. |
| Power | |
|---|---|
| Output current | 100 A |
| Performance | |
| Certification | C-tick, CE, CSA, EN 55022 Class A, EN 55024, EN 60950, EN 61000-3-2, EN 61000-3-3, GOST, UL Listed, VDE |
| Design | |
| Colour of product | Black |
| Weight & dimensions | |
| Weight | 118.2 kg |
| Operational conditions | |
| Operating temperature (T-T) | 0 – 40 C |
| Other features | |
| Dimensions (WxDxH) | 432 x 757 x 175 mm |
| I/O ports | 2 x (2PH + G) 1 x (H N + G) 2 x (2PH + N +G) 1 x (1PH+N+G) |
Smart-UPS RT 10/20 kVA Isolation/Step-Down Transformers (Manual)
Smart-UPS Accessories Heavy Duty Rail Kit Installation Guide (Sheet)
