APC SRV10KRILRK Easy UPS SRV 10kVA 230V Online UPS, Rack 5U, w/ Ext. Runtime Battery Pack, inc. Rail Kit

Call us for availability and ETA on: 0800 254 5655

Call us for availability and ETA on: 0800 254 5655

SKU:
SRV10KRILRK
MPN:
SRV10KRILRK
£4,654.50 £3,878.75
  • Over 5 minutes runtime at 70% load
  • Extended runtime model with external battery pack
  • Online double-conversion, pure sinewave UPS battery backup
  • 5U height rack-mount format (mounting kit included)
  • Easy-to-read LCD interface provides detailed & accurate UPS status information
  • High operating efficiency in energy-saving ECO mode
  • Up to 4 external battery modules (SRV240RLBP-9A) can be added for longer power availability
  • Intelligent card slot enables remote UPS monitoring
  • USB & serial connectivity
  • Input: Hardwired
  • Output: Hardwired 3-wire (1P + N + E) 1
  • 2-year repair or replace warranty
Free Express Delivery Over £99*  (1 - 2 Days)

APC by Schneider Electric offers a new category of uninterruptible power supplies (UPS) for small and medium-sized enterprises that are designed to meet even the most unstable power situations. The APC Easy UPS On-Line is a flexible, high-quality, cost-competitive UPS designed to manage a wide voltage range and consistent power conditions and deliver quality that millions of IT professionals across the world rely on.

Online double-conversion topology ensures a continually high quality of energy. Any disturbances on the distribution waveform are regenerated by converting AC to DC and then DC to AC with zero transfer time. The battery is only used as a backup power source. Pure sinewave output on the battery imitates utility power for maximum compatibility with active PFC (power factor corrected) servers and sensitive equipment. In good power conditions, the ECO operating mode bypasses unneeded electrical components to achieve high operating efficiency without losing protection, and high-efficiency rates stay consistent even at lower operating power levels.

A USB connection enables you to utilise your PC to access extra power protection and management functions for your UPS via a USB Port, and the LCD interface delivers clear and accurate information in many languages with the opportunity to customise the UPS locally using simple navigation buttons. A SmartSlot permits customization of UPS capabilities with management cards, serial connectivity enables UPS control via a serial port and network manageability enables remote UPS power management via the network.

Output

Output power capacity 10.0kWatts / 10.0kVA
Max Configurable Power (Watts) 10.0kWatts / 10.0kVA
Nominal Output Voltage 230V
Output Frequency (sync to mains) 50/60Hz +/- 3 Hz
Other Output Voltages 220, 240
Load Crest Factor 3 : 1
Topology Double Conversion Online
Waveform type Sine wave

Input

Nominal Input Voltage 230V
Input frequency 40 - 70 Hz
Input Connections Hard Wire 3-wire
Other Input Voltages 220, 240

Communications & Management

Control panel Multi-function LCD status and control console
Audible Alarm Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm

Surge Protection and Filtering

Surge energy rating 600Joules

Physical

Maximum Height 173MM, 17.3CM
Maximum Width 438MM, 43.8CM
Maximum Depth 710MM, 71.0CM
Net Weight 69.0KG
Shipping weight 79.0KG

Environmental

Operating Temperature 0 - 40 C
Operating Relative Humidity 0 - 95 %
Operating Elevation 0-3000meters
Storage Relative Humidity 0 - 95 %
Storage Elevation 0-14763.6meters

Conformance

Approvals CE, IEC 62040-1-1, IEC 62040-1-2
Standard warranty 2 years repair or replace

Sustainable Offer Status

RoHS Compliant
REACH REACH: Contains SVHCs

EASY UPS ON-LINE SRVPM6/10KRIL
User manual for Easy UPS On-Line SRVPM6KRIL and SRVPM10KRIL 230 V

APC Easy UPS On-Line SRV Brochure 1-10kVA
Product brochure which includes features and benefits, ideal applications, and product specifications for the Easy UPS On-Line 1-10kVA
