APC SMX1000I Smart-UPS X 1000VA 230V Line Interactive UPS, RT 2U

Next Day Delivery

Next Day Delivery

£911.27 £759.39

Perfect for small and medium-sized organisations wishing to protect networking critical servers and voice/data switches against power disruptions and outages.

Free Express Delivery Over £99*  (1 - 2 Days)
Free Maintenance Plan

24/7 Technical Support Number

Discounted Labour

Discounted Parts

Next Business Day Engineer Response

Click here for more information

The APC Smart-UPS X convertible extended run models are perfect for small and medium-sized organisations wishing to protect networking critical servers and voice/data switches against power disruptions and outages. This high-performance Uninterruptible Power Supply (UPS) safeguards electronic equipment from blackouts, brownouts, sags and surges, small utility power fluctuations and significant disruptions. Power capacity and run-time are reserved for connected devices that require UPS battery backup, while surge protection is provided for less critical equipment.

Smart-UPS offers hot-swap batteries, network-grade protection and built-in data line protection for worry-free uninterruptible power protection and high availability. To ensure smooth running, a handy LCD status display and audible alarms provide comprehensive status information at a glance. Additionally, automatic battery self-testing ensures early detection of a battery that needs to be replaced. The manufacturer ensures maximum protection for electronic equipment by offering a three-year repair or replace warranty (excluding battery) and two years for the battery.

Includes: CD with software, Documentation CD, Installation guide, Rack Mounting brackets, Removable support feet, Smart-UPS signalling RS-232 cable, USB cable

Features & Benefits:

  • Output power capacity: 800 Watts / 1000VA
  • 8m 6s run time for 800 watts load
  • 2U rack height
  • Auto-recognition of external batteries
  • Energy meter providing power usage for energy conscious users
  • High-efficiency Green Mode
  • Boost and trim automatic voltage regulation
  • Three-year repair or replace warranty
  • Output Connections - (2) IEC Jumpers (Battery Backup), (8) IEC 320 C13 (Battery Backup)
  • Input Connections - IEC 320 C14
  • Cord Length - 1.8m
  • Rack/Tower


Max Configurable Power (Watts)800 Watts / 1000VA
Output Voltage DistortionLess than 5 %
Output Frequency (sync to mains)50/60 Hz +/- 3 Hz Sync to mains
TopologyLine interactive
Waveform typeSine wave


Input frequency50/60 Hz +/- 3 Hz Auto-sensing
Input voltage range for main operations151 - 302 Adjustable, 160 - 286V
Number of Power Cords1

Batteries & Runtime

Battery typeLead-acid battery
Typical recharge time3hour(s)
Replacement BatteryAPCRBC116
Expected Battery Life (years)3 - 5
RBC Quantity1
Battery Charge Power (Watts)99 Watts
DC Overcurrent Protection60A
RuntimeView Runtime Graph
EfficiencyView Efficiency Graph

Communications & Management

Interface Port(s)RJ-45 Serial, SmartSlot, USB
Control panelMultifunction LCD status and control console
Audible AlarmAlarm when on battery : distinctive low battery alarm : overload continuous tone alarm
Emergency Power Off (EPO)Yes
Available SmartSlot™ Interface Quantity1

Surge Protection and Filtering

Surge energy rating600Joules
FilteringFull time multi-pole noise filtering : 5% IEEE surge let-through : zero clamping response time : meets UL 1449


Maximum Height89mm, 8.9cm
Maximum Width432mm, 43.2cm
Maximum Depth490mm, 49.0cm
Net Weight22.86kg
Shipping weight27.32kg
Shipping Height246mm, 24.6cm
Shipping Width589mm, 58.9cm
Shipping Depth620mm, 62.0cm


Operating Temperature0 - 45 °C
Operating Relative Humidity0 - 95 %
Operating Elevation0 - 3048meters
Storage Temperature-15 - 45 °C
Storage Relative Humidity0 - 95 %
Storage Elevation0 - 15240meters
Audible noise at 1 meter from surface of unit40.0dBA
Online thermal dissipation82.0BTU/hr


ApprovalsCE, EAC, EN/IEC 62040-1, EN/IEC 62040-2, Rcm, VDE
Standard warranty3 years repair or replace (excluding battery) and 2 years for battery
