Provides power protection in the event of a power outage, maintaining stable and continuous connectivity at critical times.
APC by Schneider Electric introduces Easy UPS SMV Line Interactive with Sinewave, the latest UPS designed for critical power protection demands even in the most unstable power conditions, for IT professionals in small to medium organisations. A versatile solution designed to withstand a wide voltage range and fluctuating power situations, while supplying pure sinewave output on battery backup power. This range provides the quality that millions of IT professionals around the world rely on.
Automatic Voltage Regulation (AVR) restores voltage dips and surges to optimal levels automatically, which is particularly important in low-power locations. A handy LCD graphics display and audible alarms offer notification of changing utility power to ensure smooth operation, and a mini-slot enables numerous optional management cards that provide basic or crucial monitoring, management, and control features for the Easy UPS. The manufacturer offers a two-year repair or replace warranty to maintain optimal protection for electronic equipment.
Includes: Documentation CD, USB cable, User manual
Features & Benefits:
Output | |
|---|---|
| Max Configurable Power (Watts) | 700 Watts / 1000VA |
| Output Frequency (sync to mains) | 50/60 Hz +/- 1 Hz Unsynchronised |
| Load Crest Factor | 3 : 1 |
| Topology | Line interactive |
| Waveform type | Sine wave |
| Transfer Time | 2-6 ms typical : 12 ms maximum |
Input | |
| Input frequency | 45 - 65 Hz Auto-sensing |
| Input voltage range for main operations | 165 - 290V |
| Number of Power Cords | 1 |
| Other Input Voltages | 220 V, 240 V |
Batteries & Runtime | |
| Battery type | Lead-acid battery |
| Typical recharge time | 4hour(s) |
| Nominal Battery Voltage | 24 V |
| Expected Battery Life (years) | 3 - 5 |
| Battery Charge Power (Watts) | 37 Watts |
| Battery Volt-Amp-Hour Capacity | 168 |
| Runtime | View Runtime Graph |
| Efficiency | View Efficiency Graph |
Communications & Management | |
| Interface Port(s) | Intelligent Smart Slot, USB |
| Audible Alarm | Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm |
| Available SmartSlot™ Interface Quantity | 1 |
Surge Protection and Filtering | |
| Surge energy rating | 190Joules |
Physical | |
| Maximum Height | 220mm, 22.0cm |
| Maximum Width | 160mm, 16.0cm |
| Maximum Depth | 410mm, 41.0cm |
| Net Weight | 13.6kg |
| Shipping weight | 16.6kg |
| Shipping Height | 339mm, 33.9cm |
| Shipping Width | 272mm, 27.2cm |
| Shipping Depth | 508mm, 50.8cm |
| Color | Black |
Environmental | |
| Operating Temperature | 0 - 40 °C |
| Operating Relative Humidity | 0 - 95 (Non-condensing) % |
| Operating Elevation | 0 - 3000meters |
| Storage Temperature | -10 - 40 °C |
| Storage Relative Humidity | 0 - 95 (Non-condensing) % |
| Storage Elevation | 0 - 15000meters |
| Audible noise at 1 meter from surface of unit | 45.0dBA |
| Protection Class | IP20 |
Conformance | |
| Approvals | CE, EN/IEC 62040-1, EN/IEC 62040-2 |
| Standard warranty | 2 years repair or replace |
SCHNEIDER ELECTRIC SAFETY GUIDE - EASY UPS On-Line
Schneider Electric Safety Guides for Easy UPS On-Line products use only
Easy UPS Monitoring Software
User manual for Easy UPS Monitoring Software
APC Easy UPS 1 Ph Line Interactive Brochure (SMV 750-3000 VA - 230V)
Family Brochure
