APC BX1600MI Back-UPS 1600VA/900W 230V Line Interactive UPS, IEC Output

1-2 Day Delivery

1-2 Day Delivery

SKU:
BX1600MI
MPN:
BX1600MI
£178.54 £148.78

Surge protection and battery backup for home electronics, computers and smart technology.

Free Express Delivery Over £99*  (1 - 2 Days)

The APC Back-UPS is the optimal home and office backup solution, with over two and a half minutes of autonomy at 720 watts. This enables a smooth shutdown in the case of a power outage or a sudden power outage. Furthermore, the unit has adjustable voltage sensitivity, allowing you to configure the UPS for maximum performance in specific power situations. During power outages, surges, and spikes, this UPS will backup and protect your devices and data. Surge protection is provided for less critical equipment, while power capacity and run-time are reserved for connected devices that require UPS battery backup.

To ensure smooth running, the APC Back-UPS has a handy LED status display and audible alarms to provide indicators of power conditions. In addition, battery self-test ensures early detection of a battery that needs to be replaced. The Automatic Voltage Regulation (AVR) technology restores voltage dips and surges to allowable limits, which is especially important in low-power environments. This also increases battery life by managing constant voltage changes without the use of the battery.

The manufacturer ensures maximum protection for electronic equipment by offering a two-year 'repair or replace' warranty.

Features & Benefits:

  • Output power capacity: 900 Watts / 1600VA
  • 2m 36s run time for 720 watts load
  • Battery-protected and surge-protected outlets
  • Dataline surge protection
  • Audible alerts
  • LED status display
  • Automatic Voltage Regulation
  • Two-year repair or replace warranty
  • Output Connections - (6) IEC 60320 C13 (Battery Backup)
  • Input Connections - IEC 60320 C14
  • Cord Length - 1.2m

Output

Max Configurable Power (Watts)900 Watts / 1600VA
Output Frequency (sync to mains)50/60 Hz +/- 1 Hz Sync to mains
TopologyLine interactive
Waveform typeStepped approximation to a sinewave
Transfer Time6 ms typical : 10 ms maximum

Input

Input frequency50/60 Hz +/- 5 Hz Auto-sensing
Input voltage range for main operations140 - 300V
Number of Power Cords1
Input Power Factor at Full Load0.56

Batteries & Runtime

Battery typeLead-acid battery
Typical recharge time8hour(s)
Nominal Battery Voltage24 V
Expected Battery Life (years)3 - 5
Battery Volt-Amp-Hour Capacity168
RuntimeView Runtime Graph
EfficiencyView Efficiency Graph

Communications & Management

Interface Port(s)USB
Control panelLED Status display with on line : on battery
Audible AlarmAlarm when on battery : distinctive low battery alarm

Surge Protection and Filtering

Surge energy rating273Joules
Data Line ProtectionRJ45 10/100/1000 Base-T Ethernet protection

Physical

Maximum Height190mm, 19.0cm
Maximum Width140mm, 14.0cm
Maximum Depth390mm, 39.0cm
Net Weight10.3kg
Shipping weight11.3kg
Shipping Height190mm, 19.0cm
Shipping Width140mm, 14.0cm
Shipping Depth390mm, 39.0cm
ColorBlack

Environmental

Operating Temperature0 - 40 °C
Operating Relative Humidity0 - 95 (Non-condensing) %
Operating Elevation0 - 3000meters
Storage Temperature-15 - 40 °C
Storage Relative Humidity0 - 95 (Non-condensing) %
Storage Elevation0 - 3000meters
Audible noise at 1 meter from surface of unit40.0dBA
Protection ClassIP20

Conformance

ApprovalsCB , CE, EAC, EN/IEC 62040-1, EN/IEC 62040-2
Equipment protection policyLifetime : 50000 euros
Standard warranty2 years repair or replace

Sustainable Offer Status

RoHSCompliant

User Manual for BX Series 750/950/1200/1600/2200 VA
User Manual for BX Series 750/950/1200/1600/2200 VA

Back UPS BX Series 230V Brochure

Back-UPS BX-MI (IEC) Brochure
Overview and technical specifications of Back-UPS BX-MI (IEC outlets) models
